🧠 CPU & Chipset Compatibility
Equipped with Intel® B760 chipset and LGA 1700 socket, supporting 12th, 13th, and 14th Gen Intel® Core™, Pentium® Gold, and Celeron® processors (up to 65 W) B&H Photo Video+15ASUS Global+15ASUS Global+15
💾 Memory
Offers 4 DIMM slots, supports up to 128 GB DDR5 (up to DDR5‑7200 (OC)) and DDR5 XMP via OptiMem II architecture ASUS Global+2ASUS Global+2ASUS Global+2
⚙️ Expansion & Storage
PCIe slots:
1 × PCIe 4.0 ×16 (full x16 mode)
1 × PCIe 4.0 ×16 (x4 mode via chipset)
2 × PCIe 4.0 ×16 (x1 mode) – all SafeSlot Core+ supported B&H Photo Video+7ASUS Global+7ASUS Global+7ASUS Global+4ASUS Global+4ASUS Global+4
Storage:
2 × M.2 Key‑M slots (PCIe 4.0 ×4 each)
6 × SATA 6 Gb/s ports with RAID 0/1/5/10 via Intel RST ASUS Global+15ASUS Global+15ASUS Global+15
🌐 Connectivity
Ethernet: Realtek® 2.5 Gbps LAN interface ASUS Global+4ASUS Global+4TrinWare Custom Technology Solutions+4
Wi-Fi (variant): Some models (“AX”) include Wi‑Fi 6 and Bluetooth v5.2 wireless connectivity ASUS Global+3ASUS Global+3B&H Photo Video+3
🖥 Display & USB
Video Outputs: 1 × DisplayPort, 2 × HDMI 2.1 (supports 4K @ 60 Hz) ASUS Global+4ASUS Global+4TrinWare Custom Technology Solutions+4
USB:
Rear: 2 × USB 3.2 Gen 2 Type‑A, 4 × USB 2.0
Internal: 2 × USB 3.2 Gen 1 headers (Type‑C support) + USB 2.0 headers for up to 6 ports TrinWare Custom Technology Solutions+5ASUS Global+5B&H Photo Video+5TrinWare Custom Technology Solutions+3ASUS Global+3ASUS Global+3
🔊 Audio & Cooling
Audio: Realtek 7.1 HD audio codec with PCB-level shielding, high‑grade capacitors, and front-panel jack retasking (24‑bit/192 kHz) ASUS Global+3ASUS Global+3ASUS Global+3
Thermal & Power:
Integrated VRM and M.2 heatsinks, Digi+ VRM control, Fan Xpert support
Safety via ASUS 5X Protection III: SafeSlot Core+, LANGuard, over-voltage protection, stainless-steel I/O shield, ESD guards
DIY-friendly Q‑Design: Q‑Slot, Q‑DIMM, Q‑LED diagnostics, Aura Sync with RGB/Addressable headers ASUS Global+4ASUS Global+4ASUS Global+4
📦 Box Contents
Includes motherboard, I/O shield, 2 × SATA cables, M.2 screw kit, antennas (for Wi‑Fi model), user manual, and support for ASUS software utilities like Armoury Crate, AI Suite, etc. ASUS Global+3ASUS Global+3ASUS Global+3
🛡️ Warranty Details
Standard Warranty: ASUS provides a 3-year limited warranty on all motherboards sold after November 1, 1999—this includes the Prime series such as the B760M‑A ASUS Global+15ASUS Global+15ASUS Global+15
Warranty Terms:
Coverage includes manufacturing defects and workmanship issues
Warranty becomes invalid if serial number label is removed, or if damage arises from misuse, improper installation, liquid exposure, or unauthorized repairs/disassembly ASUS Global+14ASUS Global+14ASUS Global+14ASUS Global
Region Variations: Warranty terms may vary by country; consumers should check ASUS regional support or where the board was purchased for specifics. Keeping purchase invoice is essential.
