OVERVIEW WITH WARRANTY :
Robust Build & Longevity Built with military-grade capacitors and chokes, this PSU passes stringent durability tests including MTBF testing, shock/drop resistance, vibration, extreme temperatures (−40 °C to 85 °C for 27 cycles), and corrosion resistance (up to 95% humidity with salt fog for 240 hours) . Expect dual ball-bearing fan longevity up to twice that of sleeve-bearing fans, and TUF 5K black metallic capacitors offering 52 % wider temperature tolerance and 2.5× longer lifespan .
Efficient & Forward-Looking Design Equipped with 80 Plus Gold certification (up to ~92 % efficiency), it uses low-ESR Japanese capacitors for reduced heat, improved noise control, and enhanced reliability . It’s ATX 3.0 compliant, future-ready, and includes a 16-pin PCIe Gen 5 cable capable of delivering up to 600 W to next-gen GPUs .
Smart Cooling Features ASUS’s Axial-tech 135 mm fan design—smaller hub, longer blades, barrier ring—to boost downward airflow at low RPM for quiet, efficient thermal management . “0 dB technology” ensures the fan remains off under light loads and only spins up when needed .
Modular, Flexible Cabling Fully modular with etched flexible cables (aesthetic like sleeved cables but more pliable), all of which pass rigorous UL1581 and UL758 flame tests. The comprehensive cable set includes:
24-pin MB ×1
CPU 4+4-pin ×2
PCIe Gen 5 (16-pin) ×2 + PCIe (16-pin → dual 8-pin) ×1 + PCIe 1:1 ×1
SATA ×5; 1-to-2, 1-to-3 adapter cables
Peripheral (Molex) ×4
Includes cable ties and 610–675 mm cable lengths .
Safety & Protections Comes equipped with full suite of protections: OPP, OVP, UVP, SCP, OCP, OTP, supporting safety and stability . The PCB has conformal coating for moisture, dust, and short-circuit protection.
Specifications
Form Factor: ATX12V (150 × 150 × 86 mm)
AC Input: 100–240 Vac; Active PFC
DC Rails: +3.3 V @ 25 A; +5 V @ 25 A; +12 V @ 99 A; –12 V @ 0.8 A; +5 Vsb @ 3 A (total 1200 W) .
Warranty: Manufacturer-backed 10-year limited warranty, both parts and labor
