Product Description
The Consistent H-310 Motherboard is a Micro-ATX motherboard designed to support Intel 8th and 9th Generation Core i3, i5, and i7 processors. It offers a blend of modern features suitable for mid-range desktop PC builds, balancing performance and connectivity.
Key features include:
CPU Support: Compatible with Intel 8th and 9th Gen Core i3, i5, and i7 processors.
Chipset: Intel H310 Express Chipset.
Memory: Supports dual-channel DDR4 RAM with speeds of 2133/2400/2666 MHz, up to 32GB maximum capacity.
Form Factor: Micro-ATX (approximately 17×21 cm).
Graphics Support: Integrated GMA 950 graphics, with video output options including VGA, HDMI, and DVI ports.
Sound: Onboard 6-channel HD audio codec.
Storage: Equipped with 4 SATA 3.0 (6Gb/s) ports for connecting HDDs and SSDs.
Expansion Slots: Includes 1 PCI Express x16 slot and 1 PCI Express x1 slot.
Additional Slots: NVMe M.2 slot for high-speed SSD installation.
Connectivity: USB ports including USB 3.0, USB 2.0, PS/2 keyboard and mouse ports, RJ45 LAN port with 100/1000 Mbps speed, and 3-in-1 audio ports.
Power Connectors: 24-pin ATX main power and 8-pin ATX 12V power connectors.
Cooling: 2 fan connectors for CPU and system cooling.
Integrated LAN: Supports 100/1000 Mbps Ethernet.
This motherboard is well-suited for users looking for a reliable platform to build or upgrade a desktop PC with moderate to high computing needs, including multimedia, office work, and gaming.
Warranty Information
The Consistent H-310 motherboard comes with a 3-year manufacturer warranty.
Warranty service is supported directly by Consistent Infosystems through their authorized service centers.
For warranty claims or support, customers can contact:
Email: cecare@consistent.in
Toll-Free: 1800-1034-593 (9 AM – 6 PM, PAN India)
Summary Table
| Feature | Details |
|---|---|
| CPU Support | Intel 8th & 9th Gen Core i3, i5, i7 |
| Chipset | Intel H310 Express |
| Memory | DDR4 Dual Channel, 2133/2400/2666 MHz, up to 32GB |
| Form Factor | Micro-ATX (17×21 cm) |
| Graphics | Integrated GMA 950; HDMI, VGA, DVI outputs |
| Audio | Onboard 6-channel HD Audio codec |
| Storage | 4x SATA 3.0 (6Gb/s) ports |
| Expansion Slots | 1x PCIe x16, 1x PCIe x1, 1x NVMe M.2 |
| Connectivity | USB 3.0, USB 2.0, PS/2 ports, RJ45 LAN |
| Network | 100/1000 Mbps Ethernet |
| Power Connectors | 24-pin ATX, 8-pin 12V ATX |
| Warranty Duration | 3 years manufacturer warranty |
| Warranty Support | cecare@consistent.in, 1800-1034-593 |
