Technical Specifications
Based on trusted retailer listings and MSI’s official details:
GPU: NVIDIA GeForce RTX 5060 Ti (Blackwell architecture, GB206) featuring 4,608 CUDA cores PC Gamer+14Accelerator+14ModxComputers+14Reddit+5Wikipedia+5www.guru3d.com+5
Boost Clock: Factory overclocked to around 2,647 MHz via MSI Center (court-tested peaks up to 2,776 MHz) ThePCEnthusiast
Memory: 8 GB GDDR7 at 28 Gbps on a 128‑bit bus, delivering roughly 448 GB/s bandwidth PC Studio+4Wccftech+4www.guru3d.com+4
Memory Variant: 8 GB version (also available in 16 GB variant) Reddit
Display & Interface
Interface: PCIe 5.0 ×16 (operates at ×8 lanes) Wikipedia
Display Outputs: 3 × DisplayPort 2.1b + 1 × HDMI 2.1b (supports up to 4K 480 Hz or 8K 120 Hz HDR with VRR) Accelerator+10Computech Store+10Green Apple Compunet+10
Power & Cooling
Power consumption: ~180 W TDP ModxComputers+2www.guru3d.com+2
Connector: 1 × 16-pin PCIe (12V‑2×6) connector
Recommended PSU: ~600 W system PSU Wikipedia+2Wccftech+2Reddit+8Accelerator+8ModxComputers+8
Cooling System: MSI’s Twin Frozr 10 with dual STORMFORCE fans, nickel-plated copper baseplate, core pipes, metal backplate, Wave Curved 4.0 heatsinks, Air Antegrade Fin 2.0 airflow optimization and RGB LED lighting B&H Photo Video+3Accelerator+3PC Studio+3
Dimensions & Form Factor
Dimensions: Approximately 247 × 135 × 51 mm (dual-slot form factor)
Weight: ~768 g (card) / ~1.2 kg packaged Computech Store+3ModxComputers+3Green Apple Compunet+3
Features
Supports DirectX 12 Ultimate and OpenGL 4.6, NVIDIA DLSS 4, Reflex 2, AI-accelerated rendering, G-SYNC compatibility, NVIDIA Broadcast & Studio tools, twin-fan overclocking via MSI Afterburner & MSI Center, and robust electrical protection features like DrMOS and fuse protection Computech Store+6Accelerator+6B&H Photo Video+6
Warranty Coverage
Manufacturer Warranty: Standard 3-year limited warranty from MSI on this model ThePCEnthusiast
Regional Notes (India/Others): MSI warranty is typically valid for 3 years and is tied to the original purchaser and invoice. There is no advertised extended warranty similar to Zotac’s. Always verify the warranty terms with the local authorized retailer or distributor at the time of purchase.
Performance Highlights
Boost Clock Behavior: Out-of-the-box boost speeds around 2,647 MHz, with testing showing up to ~2,776 MHz under load due to MSI’s thermal headroom ThePCEnthusiast+2www.guru3d.com+2
Platform Efficiency: Despite its compact size and relatively modest TDP, it performs well within the mid-range segment—solid 1080p and moderate 1440p capability, though limited by 8 GB VRAM for heavier modern titles PC Gamer+2wired.com+2
Summary Table
| Feature | Specification |
|---|---|
| GPU Architecture | NVIDIA Blackwell GB206 |
| CUDA Cores | 4,608 |
| Boost Clock | ~2,647 MHz (factory), up to ~2,776 MHz under load |
| Memory | 8 GB GDDR7 @ 28 Gbps |
| Memory Bus | 128-bit (~448 GB/s) |
| Interface | PCIe 5.0 ×16 (runs ×8) |
| Outputs | 3 × DisplayPort 2.1b + 1 HDMI 2.1b |
| Power Requirements | ~180 W, 1 × 16-pin connector; 600 W PSU suggested |
| Cooling Design | Twin Frozr 10 with STORMFORCE fans, core pipes, metal backplate |
| Dimensions | ~247 × 135 × 51 mm (dual-slot) |
| Weight | ~768 g |
| Software | MSI Afterburner, MSI Center, RGB control |
| Warranty | 3-year standard from MSI (non-extendable) |
Buying Tips
This 8 GB variant is best suited for 1080p gaming; for more future-proofing or 1440p needs, the 16 GB model is recommended Reddit+11www.guru3d.com+11Wccftech+11PC Gamer+2PC Studio+2B&H Photo VideoReddit
Always buy from authorized MSI retailers and retain your invoice for warranty claims.
Even though MSI's support is generally reliable, the warranty claim requires valid proof of purchase, and some regions may have different warranty policies—check the local MSI regional website.
If you're in India or a similar region, be cautious of grey-market sellers with no valid warranty support.
