Technical Specifications
Socket & Chipset: AMD AM4 platform with PRO565 chipset, supporting Ryzen 3000, 3000G, 4000G, 5000, and 5000G-series processors (Ryzen 3 3200G and Ryzen 5 3400G are not supported) tonixcomputer.co.id+10ASRock+10huge.co.za+10.
Memory Support: Four DDR4 DIMM slots, dual-channel, up to 128 GB. Supports DDR4‑4733 MHz (OC) plus ECC/non‑ECC un-buffered memory crgroup.com.sg+8geewiz.co.za+8mehtabrothers.in+8.
Power Design: 8‑phase Digi Power VRM, premium 50 A chokes, XXL aluminum heatsink, 2 oz copper PCB, and high-density glass-fabric PCB Reddit+15PB Tech+15crgroup.com.sg+15.
Expansion Slots:
1 × PCIe 4.0 ×16 (CPU)
1 × PCIe 3.0 ×16 (×4 lanes)
1 × PCIe 3.0 ×1 via chipset tonixcomputer.co.id+9geewiz.co.za+9gigabyte.comx.co.za+9gigabyte.comx.co.za.
Storage:
1 × Hyper M.2 slot (PCIe Gen4 ×4)
4 × SATA III ports with RAID 0/1/10 support sclgaming.in+11geewiz.co.za+11huge.co.za+11.
Graphics Output: HDMI output (dependent on CPU-integrated Vega graphics) huge.co.za+7geewiz.co.za+7ASRock+7.
Networking & Wireless:
Realtek RTL8111H Gigabit LAN
Intel® 802.11ac Wi-Fi (max 433 Mbps) + Bluetooth 4.2, with external antennas included gigabyte.comx.co.za+8geewiz.co.za+8xpresstech.store+8.
Audio: Realtek ALC1220 7.1-channel HD audio codec with content protection and Nahimic enhancements gigabyte.comx.co.za+7geewiz.co.za+7huge.co.za+7.
USB I/O:
Rear: 4 × USB 3.2 Gen1 (Type A), 2 × USB 2.0
Internal headers supporting 4 × front USB 3.2 and 4 × USB 2.0 ports tonixcomputer.co.id+8geewiz.co.za+8xpresstech.store+8.
Form Factor & Accessories: Micro‑ATX board (~24.4 cm × 24.4 cm), includes I/O shield, M.2 screw, Wi-Fi antennas, support manual, SATA cables sclgaming.in.
✅ Warranty & After‑Sales (India)
Warranty Coverage:
Indian retailers like SCL Gaming, and others list a 3-year carry-in warranty for this model in India sclgaming.in.
ASRock’s official policy provides only 1 year limited warranty to authorized distributors; any extended coverage beyond that is retailer‑managed and not guaranteed by the manufacturer Reddit+6Reddit+6Reddit+6.
