CP Plus HD 2.4MP Illumax Dual Light Bullet CCTV (CP-URC-TC24PL3C-L)
Product Description
Image Sensor: 2.4MP PS CMOS Sensor
Resolution: Full HD 1920×1080 pixels (2.4MP)
Lens: 3.6mm fixed lens (2.8mm and 6mm optional)
Aperture: F2.0
Minimum Illumination: 0.02lux (Color, F2.0), 0.002lux (B/W, F2.0), 0 lux (IR on)
Night Vision: Smart Dual Light (warm LED + IR); up to 30m IR range
Day/Night Function: Auto (ICR), Color, B/W
Digital Features: DWDR, 2D DNR (digital noise reduction), BLC, HLC, privacy mask (up to 8 zones)
Audio: Built-in microphone for real-time audio recording
Video Output: Supports HDCVI/HDTVI/AHD/CVBS formats (one BNC port)
Frame Rate: 1080p@25/30fps, 960H in CVBS mode
Active Deterrence: Warm LEDs can flash on event/motion (works best with SMD-supported DVRs)
DORI Distance (Detect/Observe/Recognize/Identify):
3.6mm lens: 55m / 22m / 11m / 5.5m
2.8mm and 6mm optional, distances vary
Angle of View: H: 80°, V: 43°, D: 94° (3.6mm lens)
Control: OSD menu available via coaxial cable
Casing: Bullet design, plastic housing
Weatherproofing: IP67 for robust outdoor use
Power: 12V DC ±30%, Max 3.3W (IR on)
Operating Temperature: –40°C to +60°C
Dimensions: Approx. 146.1mm × 70.0mm × 69.8mm
Weight: ~0.24kg
Special Features
Dual Light Night Vision: Combines both infrared and warm LEDs for full-color vision at night or black-and-white IR imagery in total darkness.
Active Deterrence: Warm LEDs activate on motion for advanced security.
Long-Distance Transmission: Preserves HD quality over longer cable runs.
All-in-One Compatibility: Works with a broad range of HD analog DVRs.
Built-in Mic: Enables both video and audio recording.cpplusworld+2
Warranty
Warranty Period: 2 years off-site warranty (standard on most new units).
Claim Requirements: GST bill/proof of purchase is required to avail warranty.
Warranty Type: Off-site—camera to be sent to service center for repair/replacement.
Terms: Covers manufacturing defects only; does not cover physical or water damage beyond IP67 specs. Refund is generally not provided.
Availability: Warranty valid for first purchaser and is non-transferable
