Specifications
GPU Architecture: NVIDIA Ada Lovelace – RTX 4060
CUDA Cores: 3,072 Reddit+15tpstech.in+15Computech Store+15shop.clarioncomputers.in+4zotacstore.com+4PC Studio+4
Boost Clock: ~2,475 MHz factory OC (Twin Edge OC variant) ZOTAC
Memory: 8 GB GDDR6, 17 Gbps on a 128‑bit bus (~272 GB/s) Amazon India+7tpstech.in+7Krgkart.com+7
Interface: PCIe 4.0 ×8 Reddit+15tpstech.in+15ZOTAC+15
Power Specs: ~115 W – 160 W (typical ~115 W), requires 1 × 8‑pin PCIe connector; recommended PSU ≥ 500 W Computech StoreComputech Store
Cooling & Design: IceStorm 2.0 dual-fan cooling, Freeze-Fan-Stop, compact ~221 mm length (2‑slot footprint), metal backplate, SFF‑friendly layout ZOTAC+8tpstech.in+8PC Studio+8
Display Outputs: 3 × DisplayPort 1.4a (up to 8K@60Hz), 1 × HDMI 2.1 (supports 4K@120Hz HDR / 8K@60Hz) ZOTAC+7tpstech.in+7Computech Store+7
Features: NVIDIA DLSS 3, ray tracing, SPECTRA RGB LED (on OC models), support for ZOTAC FireStorm tuning utility ZOTAC+15Computech Store+15ZOTAC+15
🛡️ Warranty Details
Standard Warranty: 3 years from date of purchase
Extended Warranty: +2 years (total 5 years) if the product is registered on ZOTAC’s official site within 28 days of purchase Krgkart.com+15tpstech.in+15Computech Store+15
Terms & Conditions:
Only the original purchaser with valid warranty invoice and intact serial number sticker is eligible
Registration must be done in the correct regional ZOTAC portal to qualify for extended coverage
Warranty does not apply to physical damage, improper use, unauthorized modifications (e.g. GPU delidding, manual fan removal), or liquid damage; mining uses may void coverage RedditReddit
⚠️ Community Notes and Caveats
Some users report warranty denial when:
Purchased units imported long ago or from specific e-commerce platforms like Flipkart; warranty is then treated from import date rather than purchase date
GPU registration mismatched region or distributor details
Reddit feedback points to ZOTAC’s strict enforcement—particularly for Indian region product registrations; delays or improper registration can lead to reduced valid warranty coverage Reddit+4Reddit+4Reddit+4Reddit+1Reddit+1
✅ Summary Table
| Feature | Details |
|---|---|
| GPU | NVIDIA RTX 4060 (Ada Lovelace) |
| CUDA Cores | 3,072 |
| Boost Clock | ≈ 2,475 MHz (OC version) |
| Memory | 8 GB GDDR6 @ 17 Gbps, 128‑bit |
| Power | ~115 W, 1 × 8‑pin; PSU ≥ 500 W |
| Interface | PCIe 4.0 ×8 |
| Cooling | IceStorm 2.0, dual-fan, Freeze Stop |
| Dimensions | ~221 mm, dual-slot compact design |
| Displays | DP ×3, HDMI 2.1 |
| Warranty | 3-year standard + 2-year extended |
| Notes | Must register within 28 days; strict regional rules |
