Chipset & CPU Support
Intel® H510 chipset (LGA 1200 socket), compatible with 10th & 11th Gen Intel® Core™, Pentium® Gold and Celeron® processors ASUS Global+12ASUS Global+12eBay+12ASUS GlobalASUS Global
Form Factor
Micro‑ATX, approx. 22.6 × 21.1 cm (8.9 × 8.3 in) ASUS Global+1ASUS Global+1
Memory
2 × DDR4 DIMM slots, up to DDR4‑3200 (OC) / 2933 / 2666 / 2400 / 2133 MHz (dual‑channel) ASUS Global+2ASUS Global+2ASUS Global+2
Graphics Output (if using CPU with integrated GPU)
1 × DisplayPort 1.4, 1 × HDMI (HDMI 2.0 for 4K @ 60 Hz when paired with 11th Gen CPUs, else HDMI 1.4 max 30 Hz), 1 × D‑Sub (VGA) ASUS Global+13ASUS Global+13ASUS Global+13
Expansion Slots
1 × PCIe 4.0/3.0 ×16 (with 11th Gen CPU supports PCIe 4.0; with 10th Gen supports PCIe 3.0)
2 × PCIe 3.0 ×1 ports ASUS Global+2ASUS Global+2ASUS Global+2
Storage
1 × M.2 slot (2242/2260/2280) supporting PCIe 3.0×4 or SATA mode
4 × SATA 6 Gb/s ports (M.2 SATA shares bandwidth with one SATA port) ASUS Global+6ASUS Global+6ASUS Global+6
USB Ports
Rear: 2 × USB 3.2 Gen 1 Type‑A, 2 × USB 2.0
Front headers: USB 3.2 Gen 1 header (2 ports), USB 2.0 headers (4 ports) ASUS Global+8ASUS Global+8ASUS Global+8
Networking & Audio
Intel® I219‑V 1 Gb Ethernet
Realtek ALC897/887 7.1‑channel audio codec with shielding, premium capacitors, front‑panel jack retasking ASUS Global+8ASUS Global+8ASUS Global+8
Cooling and Power Features
BIOS and VRM control via DIGI+ VRM & EPU, Fan Xpert utility, PCH heatsink included ASUS Global+4ASUS Global+4ASUS Global+4
Enhancements & Extras
ASUS 5X Protection III (SafeSlot Core, LANGuard, overvoltage protection, stainless‑steel back I/O)
ASUS Q‑Design (Q‑Slot, Q‑DIMM) and RGB header for Aura Sync software customization
Software: Armoury Crate, AI Suite 3, Fan Xpert, TurboV EVO, EZ Flash 3, BIOS tools, etc. ASUS Global+7ASUS Global+7ASUS Global+7
Box Contents
Motherboard, I/O shield, 2 × SATA cables, M.2 screw, support DVD, user manual ASUS GlobalASUS Global
🛡️ Warranty
Standard Warranty Length: 3 years from date of purchase (for all ASUS motherboards sold after November 1, 1999) ASUS Global+1ASUS Global+1
Warranty covers defects in materials or workmanship—not damage caused by improper installation, user modification, liquid damage, or removal of the serial number sticker.
ASUS may void warranty if the label is removed, or repairs attempted by non‑authorized personnel or centers. ASUS Global+1ASUS Global+1
Warranty terms and service availability may vary by country—check the retailer or ASUS support in your region (e.g., ASUS India support) for specifics.
