OVERVIEW :
Power & Efficiency
Offers 650 W continuous output and carries the 80 PLUS Bronze certification, delivering up to 88% operational efficiency, thereby reducing energy waste and heat.
Topology & Design
Built with LLC resonant topology plus DC-to-DC conversion for precise voltage regulation and modern system compatibility.
Cooling & Noise
Features a 120 mm thermally controlled fan—quiet at idle, ramps up only under load.
Compact Build
Slim profile with a length of 125 mm, suited to most PC cases.
Connectors
Includes:
24-pin ATX ×1
EPS (4+4) CPU ×1
PCIe (6+2) ×2
SATA ×3
Molex (PATA) ×2
Other Specifications
Single +12 V rail delivering up to 52 A (≈624 W)
MTBF: 100,000 hours
ATX12V v2.31 / EPS12V 2.92 compatibility

WARRANTY DETAILS :
5-Year Limited Warranty — Corsair stands firmly behind this PSU with a five-year coverage, providing excellent long-term reliability.
RMA Process — Warranty claims are handled through Corsair’s RMA system. You’ll need proof of purchase and the serial number for validation.
