OVERVIEW :
Power & Efficiency
Delivers 750 W continuous output, with a peak handling up to 900 W. It is certified 80 PLUS Bronze, typically achieving around 88% efficiency at 115 VAC input.
Build & Design
Non-modular ATX form factor, compact dimensions around 150 × 86 × 140 mm.
Built with a single +12 V rail design supporting ~62 A (~744 W), powered by DC-to-DC conversion for efficient voltage delivery.
Cooling & Components
Features a 120 mm hydraulic-bearing fan with intelligent RPM control for quiet operation. Includes premium Japanese capacitors and maintains ripple noise under 80 mV on +12 V and under 40 mV on +5 V/+3.3 V.
Protection & Longevity
Equipped with Active PFC, a Power Good delay of 100–500 ms, hold-up time of ≥16 ms at 70% load, and a robust MTBF of 100,000 hours.
Connectors
Provides a generous array of connectors:
ATX 20+4 pin ×1
EPS 4+4 pin ×1
PCIe 6+2 pin ×4
SATA ×8
Molex ×4
FDD adapter ×1

WARRANTY DETAILS :
Length
Backed by a 5-year manufacturer’s warranty—an indicator of Thermaltake’s confidence in the unit’s reliability.
