Platform & CPU Support
Socket/Chipset: AMD AM5 with B650 chipset
Supported CPUs: Ryzen 7000, 8000, and 9000 series processors Reddit+15ASRock+15YouTube+15Sunrise IT Park Online+2The IT Depot+2.
✅ Memory
DIMMs: 4 × DDR5 slots, dual-channel
Capacity: Up to 128 GB
Speed: Supports DDR5-6200+ (OC) or up to 7200+ MHz depending on source ASRock+10Prime ABGB+10Quiet PC+10.
✅ Power Delivery & Design
VRM: 14+2+1 phase digital DrMOS with high amperage SPS (e.g. 60A) and enlarged heatsinks for improved cooling ASRock+6ASRock+6Mostech Computers+6.
✅ Expansion & Storage
PCIe Slots:
1 × PCIe 4.0 ×16 slot (main GPU)
1 × PCIe 3.0 ×16 slot operating ×4 lanes
1 × PCIe 4.0 ×1 slot
M.2 & SATA:
1 × Blazing M.2 slot (PCIe Gen5 ×4)
1 × Hyper M.2 slot (PCIe Gen4 ×4)
1 × M.2 slot supporting PCIe Gen3/SATA3
4 × SATA III ports, RAID 0/1/10 supported Reddit+13ASRock+13The IT Depot+13Quiet PC+2ASRock+2ASRockSunrise IT Park Online+3Mostech Computers+3Flipkart+3.
✅ Graphics Output & Audio
Video Outputs: HDMI 2.1 and DisplayPort 1.4 (up to 4K @120 Hz) via iGPU
Audio: Realtek ALC897 codec with Nahimic enhancements, 7.1‑channel HD audio Krgkart.com+10Prime ABGB+10ASRock+10.
✅ Networking & USB
LAN: Realtek Dragon RTL8125BG—2.5G Ethernet
USB Ports:
USB 3.2 Gen2x2 Type-C (front)
Gen2 Type-A+C (rear), Gen2×1 more, Gen1 and USB 2.0 headers
Up to 9 × USB 2.0 ports Krgkart.com+9Prime ABGB+9ASRock+9The IT Depot+4ASRock+4ASRock+4.
✅ Other Features
BIOS Flashback button, integrated I/O shield, Thunderbolt™ AIC connector support
Supports EXPO, XMP memory profiles
Utilities: ASRock Auto Driver Installer, Post Status Checker, Polychrome Sync
ATX form‑factor (305 mm × 244 mm), 8‑layer PCB, gold‑plated PCIe contacts Flipkart+7Prime ABGB+7Ezpz Solutions+7.
✅ Warranty & After‑Sales in India 🇮🇳
Warranty
Most Indian retailers (e.g. PrimeABGB, Ezpz Solutions) list a 3-year domestic replacement warranty with invoice proof required Prime ABGB+2Ezpz Solutions+2.
ASRock’s official global policy covers only 1-year limited warranty to authorized distributors and does not guarantee extended warranty for end users—retailer-managed coverages vary in reliability Reddit.
